Hosts table
This table provides information about the host that can view LDEVs. This table is not available if
the WWN is not registered in the host to which the path is set.
DescriptionItem
The WWN of the host that can view LDEVs.HBA WWN
The host name.Host Name
Local Replication Tab
Information about the volume of the local replication pair is displayed in the Replication Properties,
and Pairs tables.
For details about each item, see the HP XP P9000 Business Copy User Guide, HP XP P9000
Business Copy for Mainframe Systems User Guide, HP XP P9000 Fast Snap User Guide, HP XP
P9000 Snapshot User Guide, or HP XP P9000 for Compatible FlashCopy Mirroring User Guide.
Replication Properties table
DescriptionItem
Displays the status of the Business Copy L1 pair.Business Copy L1
Displays the status of the Business Copy L2 pair.Business Copy L2
Displays the status of the Snapshot pair.Snapshot
Displays the status of the Fast Snap pair.Fast Snap
Displays the status of the Business Copy Z pair.Business Copy for Mainframe
Displays the status of the Compatible FlashCopy relationship.Compatible FlashCopy
Displays the status of the Compatible FlashCopy SE relationship.Compatible FlashCopy SE
If the volume is the reserved volume for the pair, Yes is displayed. If the
volume other than the reserved volume is specified, No is displayed.
Reserve Volume
Pairs table
DescriptionItem
Displays LDEV ID, LDEV Name, Emulation type, Capacity, CLPR ID, and
CLPR name of the primary volume.
Primary Volume
Displays the copy type of the pair.Copy Type
Displays the snapshot group nameSnapshot group
Displays the pair status.Status
Displays LDEV ID, LDEV Name, Emulation type, Capacity, CLPR ID, and
CLPR name of the secondary volume.
Secondary Volume
A hyphen (-) is displayed.Snapshot Date
A hyphen (-) is displayed.Pool Name(ID)
Displays the pace of copying of the pair.Copy Pace
Displays the consistency group number of the pair.CTG ID
Displays the mirror unit number of the pair.Mirror Unit
Displays the View Pair Properties.Detail
LDEV Properties window 235
