DescriptionItem
The provisioning type to be assigned to the LDEV.Provisioning Type
• Basic: Internal volume.
• THP: THP V-VOLs of Thin Provisioning
• External: External volume.
• Snapshot: Fast Snap volume or Snapshot volume
• External MF: Migration volume
Attribute of the volume indicating how the LDEV is being used.Attribute
• Command Device: Volume is a command device.
• Remote Command Device: Volume is a remote command device.
• System Disk: Volume is a system disk.
• JNL VOL: Volume is a journal volume.
• Pool VOL: Volume is a pool volume. The number in the parentheses shows the pool
identifier.
• Reserved VOL: Volume is a reserved volume.
• Quorum Disk: Volume is a quorum disk for External Storage Access Manager.
• TSE: TSE-VOL
• Online Data Migration: This volume is for online data migration.
• Hyphen (-): Volume other than the above.
Displays the access attribute of the LDEV.Access Attribute
1
The mumber of paths set for the LDEV.Number of paths
Displays the V-VOL management task being performed on a Thin Provisioning, Thin
Provisioning Z, Smart Tiers, or a Smart Tiers Z V-VOL.
V-VOL Management Task
• Reclaiming Zero Pages: The process is in progress.
• Waiting for Zero Page Reclaiming: The process has been waited.
• Hyphen (-): The process is not being performed on the LDEV.
The processor blade identifier.MP Blade ID
The resource group name and ID of which this LDEV is a member.Resource Group Name
(ID)
Opens the Create LDEVs window.Create LDEVs
Opens the LUN Paths window.Add LUN Paths
Opens the Edit LDEVs window.Edit LDEVs
Opens the Format LDEVs window.Format LDEVs
2
Opens the Delete LDEVs window.Delete LDEVs
2
Opens the Shred LDEVs window.Shred LDEVs
2
Opens the Delete LUN Paths window.Delete LUN Paths
2
Opens the Edit Command Devices windowEdit Command Device
Opens the Block LDEVs window.Block LDEVs
2
Opens the Restore LDEVs window.Restore LDEVs
2
Opens the Assign Processor Blade window.Assign MP Blade
2
Opens the Delete UUIDs window.Delete UUIDs
2
Opens the Reclaim Zero Pages window.Reclaim Zero Pages
2
Window after selecting Logical Devices 209
