Select Ports window
Available Ports table
DescriptionItem
The port identifier.Port ID
The attribute of the port indicating I/O flow.Attribute
• Initiator: Issues I/O commands to a target port when I/O is executed between storage
systems with Continuous Access Synchronous, and so on.
• Target: Receives I/O commands from a host.
• RCU Target: Receives I/O commands from an initiator when I/O is executed between
storage systems with Continuous Access Synchronous, and so on.
• External: Issues I/O commands to a target port of an external storage system with
External Storage.
Adds one or more ports selected in the Available Ports table to the Selected Ports table.Add
Removes one or more selected ports from the Selected Ports table and relocates the
ports to the Available Ports table.
Remove
