DescriptionItem
LDEV IDs may be appear for undefined LDEVs. A hyphen appearing in columns to the
right of the LDEV ID and LDEV name (for example, Parity Group ID, Pool Name ID,
Capacity, and so on) indicates the LDEV is undefined.
The LDEV names.LDEV Name
The parity group identifier where the LDEV belongs.Parity Group ID
The pool name and identifier where the LDEV belongs.Pool Name (ID)
The capacity of each LDEV.Capacity
The provisioning type of each volume:Provisioning Type
• Basic: Internal volume
• THP: V-VOLs of Thin Provisioning or Thin Provisioning Z
• External: External volume
• Snapshot: Fast Snap volume or Snapshot volume
Attribute of the volume indicating how the LDEV is used:Attribute
• Command Device: Command device
• Remote Command Device: Remote command device
• System Disk: System disk
• JNL VOL: Journal volume
• Pool VOL: Pool volume. The number in parentheses shows the pool ID.
• Reserved VOL: Reserved volume
• Quorum Disk: Quorum disk for External Storage Access Manager.
• TSE: TSE-VOL
• Online Data Migration: Volume for online data migration
• Hyphen (-): Volume in which the attribute is not defined
The journal group identifier when the attribute is JNL VOL. A hyphen indicates the
attribute is other than JNL VOL.
Journal Group ID
Adds one or more LDEVs selected in the Available LDEVs table to the Selected LDEVs
table.
Add
Removes one or more selected LDEVs from the Selected LDEVs table and relocates the
LDEVs to the Available LDEVs table.
Remove
184 Resource Partition GUI reference
