7 Troubleshooting
The information in this chapter can help you troubleshoot problems when provisioning a storage
system.
Troubleshooting VLL
If a failure occurs while you are operating, see the HP XP P9000 Remote Web Console Messages.
For the problems and solutions regarding the Remote Web Console, see the HP XP P9000 Remote
Web Console User Guide
Troubleshooting Thin Provisioning Z
The following table provides troubleshooting instructions for using Thin Provisioning Z.
Causes and SolutionsProblems
Cause:
• Shared memory for the V-VOL management area is not installed.
Solution:
• Call HP Technical Support and check if the shared memory for the
V-VOL management area is installed.
Cannot install Thin Provisioning Z.
Causes:Pool usage level exceeds the threshold.
• Too many THP V-VOLs are associated with a pool, or too much data
is stored in a pool.
• Capacity of the pool is insufficient.
• The threshold of the pool is too low.
Solutions:
• Add some pool-VOLs to increase the capacity of the pool. See
“Increasing pool capacity” (page 123).
• Perform the operation to reclaim zero pages in order to release pages
in which zero data are stored. See “About releasing pages in a THP
V-VOL” (page 130).
• Set a larger value to the threshold of the pool. See “Changing pool
thresholds” (page 119).
After correcting the causes of SIM 620XXX, or 620XXX and 626XXX,
you need to complete the SIMs (see “Manually completing a SIM”
(page 121)). If you do not complete the SIMs, no new SIM will occur
even if the usage level increases and again exceeds the threshold (target
SIM codes are 620XXX, and 626XXX).
SIMs 620XXX, 625000, and 626XXX are automatically completed if
you increase pool capacity by adding pool-VOLs, because the condition
that caused the SIM is removed.
Caution: You need free volumes to add as pool-VOLs. If there are no
free volumes, create new volumes or ask HP Technical Support to add
drives. Therefore, it may take time to solve the problem.
Causes:Cannot create a THP V-VOL.
• Usage of the pool has reached to 100%.
• Something in the storage system is blocked.
• Too many THP V-VOLs are assigned, or Subscription Limit is too low.
