6. In the Confirm window, confirm the settings, in Task Name type a unique name for this task
or accept the default, and then click Apply.
If Go to tasks window for status is checked, the Tasks window opens.
Working with SIMs
About SIMs
Thin Provisioning Z provide Service Information Messages (SIMs) to report the status of the THP
V-VOLs and pools. The SIM level is Moderate. If an event associated with a pool occurs, a SIM is
output to Remote Web Console to alert the user, and an SNMP trap is reported to the open-systems
host.
An example of a SIM condition is if the actual pool usage rate is 50.1%, but only 50% appears
on in Remote Web Console because the capacity amount is truncated after the decimal point. If
the threshold is set to 50%, a SIM and an SNMP trap are reported, even though the pool usage
rate appearing in Remote Web Console does not indicate the threshold is exceeded.
SIM reference codes
The following table provides information about SIM reference codes associated with Thin
Provisioning Z or Smart Tiers.
Types of reportsThresholds or ValuesEventSIM Code (XXX
= hexadecimal
pool number)
Information to the
operator
Completion
report to Remote
Web Console
Report to the
host
NoYesYes1% to 100% (in 1%
increments).
Pool usage level
exceeded the
Warning Threshold
620XXX
Default: 70%
NoYesYes100%Pool is full622XXX
YesNoYesNot applicableError occurred in the
pool
623XXX
YesYesYesNot applicableNo space in the
shared memory
624000
NoYesYesHighest pool thresholdPool usage level
continues to exceed
625000
the highest pool
threshold. SOM 734
must be enabled.
NoYesYes1% to 100% (in 1%
increments).
Pool usage level
exceeded the
Depletion Threshold
626XXX
Default: 80%
YesNoYesNot applicablePool-VOL is blocked627XXX
Automatic completion of a SIM
Some SIMs are completed automatically when you resolve the problem that caused the SIM. SOM
734 must be enabled for automatic completion of a SIM. Automatic completion of a SIM removes
it from the system with no additional manual intervention. After the SIM is automatically completed,
the status of the SIM changes to completed in Remote Web Console in the Confirm window.
120 Configuring thin provisioning
