DescriptionItem
• Port ID: The port name of the P-VOL LDEV’s LUN path.
For BC Z, this item is blank.
• Host Group Name: The host group name of the P-VOL LDEV’s LUN path.
For BC Z, this item is blank.
• LUN ID: The LUN ID of the P-VOL LDEV's LUN path.
For BC Z, this item is blank.
• Emulation Type: The P-VOL’s emulation type.
• Capacity: The P-VOL’s volume capacity.
(FS only.)Snapshot Group
The snapshot group name.
If you have not set a snapshot group for FS pairs, this item is blank.
(FS only.)New Snapshot Group
Values:
• Yes: New snapshot group is used.
• No: Existing snapshot group is used.
Secondary Volume
• LDEV ID: The S-VOL’s LDEV identifier.
• LDEV Name: The S-VOL’s LDEV name.
• Port ID: The port name of the S-VOL LDEV’s LUN path.
For BC Z, this item is blank.
• Host Group Name: The host group name of the S-VOL LDEV’s LUN path.
For BC Z, this item is blank.
• LUN ID: The LUN ID of the S-VOL LDEV's LUN path.
For BC Z, this item is blank.
• Emulation Type: The S-VOL’s emulation type.
• Capacity: The S-VOL’s volume capacity.
The following types of pairs are shown:Copy Type
• BC-L1: BC L1
• BC-L2: BC L2
• FS: FS
• SS: SS
• BC Z: BC Z
The mirror unit number.Mirror Unit
For FS and SS pairs, a hyphen (-) is shown.
(BC/SS and BC Z only.)Split Type
One of the following selected split types are shown:
• Non Split: Does not split the pair.
• Quick Split: Splits the pair immediately
• Steady Split: Splits the pair after all differential data is copied
(BC/SS and BC Z only.)Copy Pace
The speed at which the split operation is performed.
Values: Faster, Medium, Slower
Create Pairs wizard 95
