DescriptionItem
The emulation type of LDEVEmulation Type
The capacity of LDEV.Capacity
The cLPR numberCLPR
The number of S-VOL.Number of Secondary Volumes
(BC only) The number for an L1 pair does not include the number of L2 S-VOL.
(FS and SS only.)Primary Volume
Information about the P-VOL.
Values:
• LDEV ID: The P-VOL’s LDEV identifier:
• LDEV Name: The P-VOL’s LDEV name.
• Port ID: The port name of the P-VOL LDEV’s LUN path.
• Host Group Name: The host group name of the P-VOL LDEV’s LUN path.
• LUN ID: The LUN ID of the P-VOL LDEV's LUN path.
• Emulation Type: The P-VOL’s emulation type.
• Capacity: The P-VOL’s capacity.
• CLPR: The P-VOL’s CLPR number.
(FS and SS only.)Mirror Unit
The mirror unit number.
(FS and SS only.)Pool Name (ID)
The pool name and identifier.
Select Secondary Volumes window
Use this window to select LDEVs that are the S-VOL.
92 Business Copy GUI reference
