Consistency Group Properties table
DescriptionItem
The consistency group identifierCTG ID
The consistency group statusStatus
• BC Used: The consistency group is in use by BC.
• BC Z Used (RAID Manager): The consistency group is used by BC Z and
managed with RAID Manager.
• BC Z Used (PPRC/BCM): The consistency group is used by BC Z and managed
with PPRC/BCM.
• FS Used: The consistency group is used by FS.
• SS Used: The consistency group is used by SS.
• Mainframe Reserved: Consistency group is reserved for use by PPRC and
BCM.
• Free: The consistency group is not being used and is not reserved.
• (Changing...): Status is the process of changing.
The number of pairs assigned to the consistency groupNumber of Pairs
Consistency Group Properties window 87
