Summary tab
DescriptionItem
The number of pairs for each local replication software typeNumber of Pairs
The number of consistency groups whose status is other than FreeNumber of Consistency Groups
The number of reserved volumes.Number of Reserve Volumes
Values:
• Open: Number of OPEN system reserved volumes
• Mainframe: Number of mainframe system reserved volumes
• Total: Total reserved volumes
• Total including S-VOLs: Includes number of reserve volumes and number of
S-VOL for BC, BC Z, FS, and SS.
The estimated FS pair capacity. An icon is shown, , when the value is less
than 128 TB. For more information, see the HP XP P9000 Fast Snap User Guide.
Snapshot Estimated Manageable
Capacity
The number of pair tables in use for the following:Number of Pair Tables
• BC/BC Z/Auto LUN: BC, BC Z, Auto LUN
• FS/SS: FS and SS
(BC, BC Z, and SS only.)Number of Differential Tables
The number of differential tables in use.
Click to open the Edit Local Replica Options window.Edit Local Replica Options button
Click to open the Edit SCP Time window.Edit SCP Time button
Pairs tab
The Pairs tab shows only pairs to which you are allocated the P-VOL and/or S-VOL.
DescriptionItem
Primary Volume
• LDEV ID: The P-VOL’s LDEV identifier. Click to open the LDEV Properties
window.
• LDEV Name: The P-VOL’s LDEV name.
• Port ID: The port name of the P-VOL LDEV’s LUN path.
For BC Z, a hyphen (-) is shown.
• Host Group Name: The host group name of the P-VOL LDEV’s LUN path.
For BC Z, a hyphen (-) is shown.
• LUN ID: LUN identifier of the P-VOL LDEV's LUN path.
For BC Z, a hyphen (-) is shown.
• Capacity: The P-VOL’s capacity.
• CLPR: The P-VOL’s CLPR number.
Shows the following types of pairs:Copy Type
• BC-L1: BC/SS L1
• BC-L2: BC/SS L2
• FS: FS
• SS: SS
• BC Z: BC Z
Local Replications window 77
