Replica LDEVs tab
DescriptionItem
The selected LDEV’s identifierLDEV ID
The selected LDEV’s nameLDEV Name
The selected LDEV’s emulation typeEmulation Type
The selected LDEV’s capacityCapacity
Shows the following copy types:Copy Type
• BC-L1: BC L1 P-VOL or S-VOL
• BC-L2: BC L2 P-VOL or S-VOL
• FS: FS P-VOL or S-VOL
• SS: SS P-VOL or S-VOL
• BC Z: BC Z P-VOL or S-VOL
• FC Z: Compatible FlashCopy relationship
• FCSE: Compatible FlashCopy SE relationship
Click to open the dialog box for downloading table information to a file.Export button
Local Replications window
Use this window to view pair, reserve volume, and consistency group information for local
replication. Use it also to perform the following operations:
• “Creating pairs” (page 43)
• “Splitting pairs” (page 47)
• “Resynchronizing pairs” (page 50)
• “Deleting pairs” (page 51)
76 Business Copy GUI reference
