B Business Copy GUI reference
This appendix describes BC windows and dialog boxes in RWC.
Replications window
Use this window to view pair information for local replication.
Summary tab
DescriptionItem
The used and licensed capacity of each product.Licensed Capacity
The number of LDEVs used for all local replication pairs.Number of Replica LDEVs
The number of relationships that Compatible FlashCopy and Compatible
FlashCopy SE use.
Number of FC Z/FCSE Relationships
(BC, BC Z, and SS only.)Number of Differential Tables
Number of differential tables in use.
Click to open the View History window.View Histories button
Replications window 75
