Related information
• “Local Replications window” (page 76)
Monitoring reserve volumes
You can see the number of reserve volumes and a list of the individual reserve volumes and their
details.
• View the number of reserve volumes in the Summary section of the Local Replications window.
• View a list of reserve volumes and their details on the Reserve Volumes tab in the Local
Replications window.
Related information
• “Local Replications window” (page 76)
Monitoring a pair’s operation history
You can review the operations that have been performed on a pair using the View History window.
1. In the tree, click Replications > Local Replications.
2. Click View Histories.
3. In the View Histories window, select BC from the Copy Type list.
4. The Description column shows the operation that was run.
The following table shows a list of the codes.
ExplanationDescriptionCode
Initial copy began.PAIR START4710
Initial copy completed and pair status changed to SMPL.PAIR END4720
Pair split operation began.PSUS START4730
Pair split completed and pair status changed to PSUS.PSUS END4740
Pair resync operation began.COPY(SP)/COPY START4750
COPY(RS-R)/RCPY START
Pair resync operation completed and pair status changed
to PAIR.
COPY(SP)/COPY END
COPY(RS-R)/RCPY END
4760
The pair was deleted and status changed to SMPL.SMPL(PD) DELETE4780
58 Monitoring and maintaining the system
