The following table shows the BC operations that you can perform when the P-VOL is shared with
Cnt Ac-J S-VOL/P-VOL at intermediate site.
BC operationsCnt Ac-J
intermed.-remote
pair status
Cnt Ac-J
local-intermed.
pair status
Resync -- Quick
Restore
Resync --
Reverse Copy,
Create, Split, Suspend, Delete,
Resync--Normal Copy, Quick Resync
NONOYESPAIR or
COPY(PD)/COPY
PAIR,
COPY(PD)/COPY*,
and
PSUS/SSWS
NONOYESPSUS/SSWSPAIR or
COPY(PD)/COPY
NOYESYESPSUS/SSWSPSUS/SSWS
* You cannot perform BC operations if the status for both Cnt Ac-J pairs is COPY(PD)/COPY.
The following table shows the BC operations that you can perform when the P-VOL is shared with
Cnt Ac-J S-VOL at remote site.
BC operationsCnt Ac-J
intermed.-remote pair
status
Resync -- Reverse Copy,
Quick Restore
Create, Split, Suspend, Delete,
Resync--Normal Copy, Quick Resync
NOYESPAIR or
COPY(PD)/COPY
YESYESPSUS/SSWS
Sharing volumes in a 3-Cnt Ac-J DC delta resync (cascade) configuration
The cascade delta resync configuration with shared BC volumes is shown in the following figure.
You can share BC P-VOLs with the delta resync P-VOL and the S-VOL.
Figure 4 BC volumes in a delta resync (cascade) configuration
When a delta resync pair is part of the 3 DC cascade configuration, supported operations for BC
pairs are dependent on the Cnt Ac-J pairs.
