Sharing volumes in a 3-Cnt Ac-J DC cascade configuration
You can share BC volumes with Cnt Ac-J volumes in 3 DC cascade configurations. You can share
BC P-VOL and S-VOLs with Cnt Ac-J volumes, as shown in the following figure.
Figure 3 BC volumes in a 3-Cnt Ac-J DC cascade configuration
When associated with these configurations, BC pair operations are dependent on the pair status
of the Cnt Ac-J local-intermediate pair and the local-remote pair.
The following table shows the BC operations that you can perform when the P-VOL is shared with
Cnt Ac-J P-VOL at local site.
BC operationsCnt Ac-J
local-intermed. pair
status
Resync--Reverse Copy and Quick RestoreCreate, Split, Suspend, Delete,
Resync--Normal Copy, Quick Resync
NOYESPAIR or
COPY(PD)/COPY*
YESYESPSUS/SSWS
The following table shows the BC operations that you can perform when the S-VOL is shared with
Cnt Ac-J P-VOL at local site.
BC operationsCnt Ac-J local-intermed. pair status
Resync - all typesSuspend, DeletePair splitPair create
NOYESNONOPAIR
NOYESNONOCOPY(PD)/COPY
YESYESYESNOPSUS/SSWS
Continuous Access Journal 31
