For more information about these configurations, see the HP XP P9000 Continuous Access Journal
User Guide.
Sharing volumes in a 3-Cnt Ac-J DC multi-target configuration
You can share BC volumes with Cnt Ac-J volumes in 3 DC multi-target configurations. You can
share the BC P-VOL and S-VOLs with Cnt Ac-J volumes, as shown in the following figure.
Figure 1 BC volumes in a 3-Cnt Ac-J DC multi-target configuration
In these configurations, BC pair operations are dependent on the pair status of the Cnt Ac-J
local-intermediate pair and the local-remote pair.
The following table shows the supported BC operations when the P-VOL is shared with Cnt Ac-J
P-VOL.
BC operationsCnt Ac-J
intermed.-remote
pair status
Cnt Ac-J
local-intermed.
pair status
Resync -- Quick
Restore
Resync --
Reverse Copy,
Create, Split, Suspend, Delete,
Resync--Normal Copy, Quick Resync
NONOYESPAIR or
COPY(PD)/COPY
PAIR,
COPY(PD)/COPY*,
and PSUS/SSWS
NONOYESPSUS/SSWSPAIR or
COPY(PD)/COPY
NOYESYESPSUS/SSWSPSUS/SSWS
* You cannot perform BC operations if the status for both Cnt Ac-J pairs is COPY.
The following table shows the supported BC operations when the S-VOL is shared with Cnt Ac-J
P-VOL.
BC operationsCnt Ac-J
intermed.-remote
pair status
Cnt Ac-J
local-intermed.
pair status
ResyncSuspend,
Delete
SplitCreate
Quick RestoreNormal Copy, Quick
Resync, Reverse Copy
NONOYESNONOPAIR or
COPY(PD)/COPY*
COPY(PD)/COPY*,
or PSUS/SSWS
NONOYESNONOPSUS/SSWSPAIR or COPY
NOYESYESYESNOPSUS/SSWSPSUS/SSWS
* You cannot perform BC operations if the status for both Cnt Ac-J pairs is COPY(PD)/COPY.
