DescriptionField
The date and time of the operation.Date
The LDKC:CU:LDEV of the P-VOL used in the operation.P-VOL
The LDKC:CU:LDEV of the S-VOL used in the operation.S-VOL
The BC reference codes. The codes refer to the messages shown in the following table.Code
The description of the operation or part of an operation.Message
Table 14 Reference Codes
DescriptionMessageCode
The initial copy started.PAIR START4710
The initial copy ended, and the pair status changed
to PAIR.
PAIR END4720
The pair split started.PSUS START4730
The pair split ended, and the pair status changed to
PSUS.
PSUS END4740
Resynchronization of pairs started.COPY(RS)/COPY START4750
COPY(RS-R)/RCPY START
Resynchronization of pairs ended, and the pair status
changed to PAIR.
COPY(RS)/COPY END
COPY(RS-R)/RCPY END
4760
The pair was deleted, and the pair status changed to
SMPL.
SMPL4780
The pair was suspended, and the pair status changed
to PSUE.
PSUE4790
A copy ended abnormally (reason other than above).COPY ABNORMAL END47D0
138 Business Copy GUI reference (secondary window)
