Preview list
The Preview list is shown below the Volume list. It shows the pair operations and changes you
have made. You can review your changes, make modifications, and apply them to the storage
system.
DescriptionField
The P-VOL information in AAA-BB-CCC(XX:YY:ZZ) format.P-VOL
• AAA is the port ID (cluster and channel number)
• BB is the group number of host group
• CCC is the LU number
• XX:YY:ZZ is the LDKC number:CU number:LDEV number
The MU number of the BC pair formed with the P-VOL.MU
The S-VOL information in AAA-BB-CCC(XX:YY:ZZ) format.S-VOL
• AAA is the port ID (cluster and channel number)
• BB is the group number of host group
• CCC is the LU number
• XX:YY:ZZ is the LDKC number:CU number:LDEV number
The speed that data is copied according to the pair status.Copy Pace
The P-VOL’s cache logical partitionCLPR (P)
The S-VOL’s cache logical partitionCLPR (S)
If you click Apply and then the operations in the Preview list fail, an error code indicates
the cause of the error.
Error Code
Data in the status bar below the Preview list indicate the number of changes, the type of change
(the operation), and any command options.
Pair Operation command menu
Right-click a volume or pair to open the pair operation command menu. The following table
describes the commands that display in the menu.
DescriptionCommand
Opens the Detail dialog box, which shows detailed information for the selected volume or
pair.
Detail
Opens the Paircreate dialog box, in which you create new pairs.Paircreate
Opens the Pairsplit dialog box, in which you split pairs.Pairsplit
Opens the Pairresync dialog box, in which you resynchronize pairs.Pairresync
Opens the Pairsplit-E dialog box, in which you suspend pairs.Pairsplit-E
Opens the Pairsplit-S dialog box, in which you delete pairs.Pairsplit-S
Opens the Set/Reset Reserve Attribute dialog box, in which you set/reset the S-VOL reserve
attribute.
Change Reserve
Opens the S-VOL Path dialog box, which shows S-VOL’s port or host group.S-VOL Path
Opens the Information dialog box, which shows number of pairs or reserved volumes.Information
136 Business Copy GUI reference (secondary window)
