2 Requirements and planning
This chapter describes system requirements and recommendations for planning a BC system.
System requirements
The following table shows minimum requirements for BC.
RequirementItem
Based on purchased capacity. For more information, see “License capacity requirements”
(page 13).
BC license capacity
Must be installed.License key
For more information about installation, see the HP XP P9000 Remote Web Console User
Guide.
RAID 1, RAID 5, RAID 6RAID level
If you are using the previous version of RWC, which is shown in a secondary window,
you must be in Modify mode to perform pair operations.
RWC
Requires a command device when used in In-Band mode, though not for Out-of-Band
mode.
RAID Manager
For more information, see the HP XP P9000 RAID Manager User Guide.
Pair volumes
• Number of P-VOLs per S-VOL: one
• Number of S-VOLs per P-VOL:
For L1 pairs, a maximum of three S-VOLs per P-VOL.
For L2 pairs, a maximum of two S-VOLs per P-VOL.
(For information on pair-layers, see “Cascaded pairs” (page 8)).
• Volume Capacity: P-VOL and S-VOLs must have the same capacity.
• Supported volume types:
- Internal system volumes.
- External volumes. External Storage (Ext Stor) license required.
- Custom-sized volumes. VLL required. Pair volumes must have same capacity and
emulation type.
- LUSE volumes require LUSE license. BC S-VOLs must have the same size and structure
as the P-VOL. For example, if the P-VOL is a LUSE volume in which volumes of 1 GB,
2 GB, and 3 GB are combined in this order, the S-VOL must also be a LUSE volume
with volumes of 1 GB, 2 GB, and 3 GB combined in the same order.
• MU number (mirror unit number):
- For an L1 pair, use 0, 1, or 2.
- For an L2 pair, use 1 or 2.
• Sharing volumes with other software products is supported. See “Sharing Business
Copy volumes” (page 23).
• The following cannot be used as pair volumes:
- Continuous Access Journal (Cnt Ac-J) journal volumes.
- Virtual volumes (except Thin Provisioning volumes).
- Pool volumes.
Per storage system: 16,384 pairs (when one S-VOL per P-VOL). Actual number is based
on amount of additional shared memory. See “Planning number of pairs” (page 13) for
further information.
Maximum number of pairs
12 Requirements and planning
