DescriptionItem
Secondary Volume
• LDEV ID: The S-VOL’s LDEV identifier.
• LDEV Name: The S-VOL’s LDEV name.
• Emulation Type: The S-VOL’s emulation type.
• Capacity: The S-VOL’s volume capacity.
• CLPR: The S-VOL’s CLPR number.
(FS and SS only.)Snapshot Date
The date and time that a snapshot was acquired.
For BC/SS and BC Z, a hyphen (-) is shown.
(FS and SS only.)Pool Name (ID)
The pool name and identification number.
For BC/SS and BC Z, a hyphen (-) is shown.
The mirror unit number.Mirror Unit
Edit Mirror Units dialog box
Use this dialog box to change mirror unit numbers.
DescriptionItem
The mirror unit number assigned to L1 and L2 volumes (BC/SS only). For more
information, see the step on MU number in “Creating pairs” (page 43).
Mirror Unit
Change Options dialog box
Use this dialog box to change the Split Type and Copy Pace. The changes you make in this dialog
box applies to all new pairs you create.
106 Business Copy GUI reference
