DescriptionItem
Secondary Volume
• LDEV ID: The S-VOL’s LDEV identifier
• LDEV Name: The S-VOL’s LDEV name
• Emulation Type: The S-VOL’s emulation type
• Capacity: The S-VOL’s volume capacity
• CLPR: The S-VOL’s CLPR number
(FS and SS only.)Snapshot Date
The date and time that a snapshot was acquired.
For BC/SS and BC Z pairs, a hyphen (-) is shown.
(FS and SS only.)Pool Name (ID)
The pool name and identification number.
For BC/SS and BC Z pairs, a hyphen (-) is shown.
The mirror unit number.Mirror Unit
The type of resynchronization is specified:Resync Type
• Normal Copy (Primary > Secondary)
• Reverse Copy (Secondary > Primary)
• Quick Resync (Primary > Secondary)
• Quick Restore (Secondary > Primary)
For more information, see “Types of resync operations” (page 48).
(BC/SS and BC Z only.)Copy Pace list
The speed at which the split operation is performed.
Values: Faster, Medium, Slower
Default: Medium
For FS and SS pairs, a hyphen (-) is shown.
Confirm window
102 Business Copy GUI reference
