HP XP P9000 Audit Log User and Reference Guide

Domain Name,Base DN,Search User's DN,Timeout,Retry Interval,
Number of Retries}=
-{Enable,CFFILE,STARTTLS,Disable,
-example.com,389,example1.com,
-dc=example2 dc=com,example3.com,10,1,3}
+Num. of Servers=1
Basic Information for Example 3
DescriptionParameter
Indicates that the RADIUS server is used as the External Authentication server.RADIUS
Detailed Information for Example 3
DescriptionItem
Indicates the RADIUS protocol to useAuthentication Protocol
PAP: password authentication protocol that transmits plaintext user ID and password
CHAP: challenge-handshake authentication protocol that transmits encrypted password
Indicates the host name of the RADIUS serverPrimary Host Name
Indicates the identifier for the RADIUS server to find SVPNAS Address
Indicates the port number of the RADIUS serverPrimary Port Number
Indicates the number of seconds before connection to the RADIUS server times outTimeout
Indicates the number of times that the system tries to reconnect to the server when the
connection to the RADIUS server fails
Number of Retries
Indicates whether to use a secondary RADIUS server or a secondary LDAP serverSecondary Server
Enable: Use the secondary server
Disable: Do not use the secondary server
Indicates the host name of the secondary RADIUS serverSecondary Host Name
Indicates the port number of the secondary RADIUS serverSecondary Port Number
Indicates whether to connect an authentication server to an authorization serverExternal User Group
Mapping
Enable: Connects an authentication server to an authorization server
Disable: Does not connect an authentication server to an authorization server
Indicates the name of certification fileCertification File Name
Indicates the LDAP protocol to useAuthentication Protocol
Indicates whether to search for the LDAP server using the information registered in the SRV
records in the DNS server
DNS Lookup
Enable: Performs the search using information registered in the SRV records in the DNS
server
Disable: Performs the search using the host name and the port number
Indicates the host name of the LDAP serverHost Name
Indicates the port number of the LDAP serverPort Number
Indicates the domain name that the LDAP server managesDomain Name
Indicates the Base DN for searching for users to authenticateBase DN
Commas that are input by user are indicated with spaces
Indicates the DN of the user for searchingSearch User's DN
52 Audit log examples
