Figure 88 Extra Command Device Direct Operation Panel
Table 66 (page 99) describes the items displayed in the Extra Command Device Direct Operation
panel.
Table 66 Contents of the Extra Command Device Direct Operation Panel
DescriptionItem
Route list ID selected in the Manage Route panelRoute List ID
You can operate command devices on a DAD that includes command
devices defined in the displayed route list ID.
If you press the F5=Extra key without specifying a route list ID in the Manage
Route panel, the message *** Route List is not selected ***
will be displayed.
Specify an action.AC
• q: Displays command device information registered in the storage system.
The Command Device Status panel is displayed.
• d: Deletes command device information registered in the storage system.
The Command Device Status panel is displayed.
You need to specify all input columns to execute an action.
Results of the action
1
Status
• Del,nn: Displays the results (return code) of deletion processing for the
command device, in nn.
• Qry,nn: Displays the results (return code) of display processing for the
command device information, in nn.
Specify the DAD ID, using alphanumeric characters (required).Device Address Domain ID
Do not use hyphens.
If no route list ID is specified (that is, when this panel is displayed from the
Manage Route panel), operations can only be performed for local command
devices. In this case, you cannot overwrite DAD IDs that are already
displayed.
Specify the storage system serial number, using 5 digits of alphanumeric
characters (required).
Serial Number
Use a 4-digit hexadecimal to specify the device number of the command
device (required).
Devn
