HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Figure 86 Panel Transitions from the Manage Route Panel
The Manage Route panel is shown in Figure 87 (page 98).
Figure 87 Manage Route Panel
“Contents of the Manage Route Panel” (page 98) describes the items in the Manage Route panel.
Table 65 Contents of the Manage Route Panel
DescriptionItem
Specify an action.
• s: Displays the Route Status panel used to display the information on the route list ID.
AC
Route list IDRoute List ID
Extra Command Device Direct Operation Panel
In the Manage Route panel and Route Status panel, press the F5=Extra key to display the Extra
Command Device Direct Operation panel. You can use the Extra Command Device Direct Operation
panel to perform operations (aside from registration) for command devices not defined in the route
list.
Figure 88 (page 99) shows the Extra Command Device Direct Operation panel.
98 ISPF Panels
