HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Figure 66 Copy Group Detail Definition Panel
“Items in the Copy Group Detail Definition panel” (page 74) describes the items in the Copy Group
Detail Definition panel. Note that changes for each item will be applied to the storage system
settings when the copy pair is reloaded (by executing the YKLOAD command) and then created.
For Continuous Access Synchronous for Mainframe copy pairs with the HyperSwap attribute,
because Business Continuity Manager cannot perform copy pair operations, if you change the
definitions of the items that require the YKMAKE command to make changes, the changes will not
be applied to the storage system settings.
Table 54 Items in the Copy Group Detail Definition panel
When effectiveDescriptionItem
When the YKMAKE
command is executed
1
Copy type of the copy groupCopy Group Type
N/ACopy group IDCopy Group ID
N/APrimary DAD IDPrimary Device Address
Domain
N/ASecondary DAD IDSecondary Device Address
Domain
When the YKMAKE
command is executed
1
.
Specify / to define an EXCTG attribute.
2
This is only effective when the copy type is CAJ; if the copy
type is other than CAJ, an error message is displayed.
Enable EXCTG Attributes
When the YKMAKE
command is executed.
Specify an EXCTG ID (0 to 3) for copying in the forward
direction.
EXCTG ID (Forward)
Unless all volumes are
SIMPLEX, execution
might not be executed
properly.
1
When the YKMAKE
command is executed.
1
Specify an EXCTG ID (0 to 3) for copying in the reverse
direction.
EXCTG ID (Reverse)
When the YKMAKE
command is executed.
1
Select to define a container.
This check box cannot be cleared if there are multiple copy
groups.
Use Container
N/ASpecify an action.AC
• e: Edits a copy pair in the copy group. This setting
displays the Copy Group Pair Detail panel (this setting
74 ISPF Panels
