HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 49 Contents of the Edit Port Definition Panel (continued)
DescriptionItem
Secondary CU numberCU
Secondary SSIDSSID
Specify an action.AC
d— Deletes a physical path.
When actions are entered in multiple AC columns, each is processed in the
order displayed.
Port number of the physical path of the primary sitePrimaryPort
Direction of the pathDir
Port number of the physical path of the secondary siteSecondary
In the initial state, the information is displayed in ascending order by hexadecimal code in the
following order: Primary and then Secondary for Port.
Assign Port Panel
When you press F5=Add in the Edit Port Definition panel, the Assign Port panel is displayed for
assigning new physical paths.
Figure 59 (page 68) shows the Assign Port panel.
Figure 59 Assign Port Panel
Table 50 (page 68) describes the items in the Assign Port panel.
Table 50 Contents of the Assign Port Panel
DescriptionItem
Port number of the primary sitePrimary Port Number
Port number of the secondary siteSecondary Port Number
Sort Logical Paths in Path Set Panel
When F6=Sort is pressed in the Path Set Detail panel, the Sort Logical Paths in the Path Set panel
is displayed.
Figure 60 (page 69) shows the Sort Logical Paths in the Path Set panel.
68 ISPF Panels
