HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Figure 56 Select Storage System Panel
Table 47 (page 66) describes the items in the Select Storage System panel.
Table 47 Contents of the Select Storage System Panel
DescriptionItem
Specify an action.AC
s— Displays the Select SSID panel used to load a disk configuration
definition file.
When actions are entered in multiple AC columns, the top line is selected.
Storage system serial numberS/N
DAD IDDevice Address Domain ID
In the initial state, the information is displayed in order by ascending EBCDIC code, prioritized as
follows: S/N, and then Device Address Domain ID.
If s is specified in AC and Enter is pressed, the disk configuration definition file is loaded and the
Model and IFType values are fetched. At this point, if DKC is not specified in Type in the Edit
Logical Path Definition panel, the Select SSID panel is displayed for displaying a list of CUs in the
storage system on the selected line.
Select SSID Panel
For a CU logical path, if s is specified in the AC column in the Select Storage System panel, the
Select SSID panel is displayed with a list of CUs in the storage system.
Figure 57 (page 66) shows the Select SSID panel.
Figure 57 Select SSID Panel
Table 48 (page 67) describes the items in the Select SSID panel.
66 ISPF Panels
