HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Length (characters)Data type
1
Value to be specifiedItem name
1 - 5AlphanumericStorage system serial
number of the secondary
site
2
SSN
1 - 2HexadecimalCU number of the secondary
site
2
SCU
1 - 2HexadecimalCCA number of the
secondary site
2
SCCA
1 - 2Hexadecimal for other than
CAJ:
Consistency group IDCTID
Specify in the range from 00
to 7F
For CAJ:
Specify in the range from 00
to FF.
1 - 2HexadecimalSubconsistency group IDSubCTID
Specify in the range from 00
to FF.
1 - 5DecimalNumber of times the
specified copy pair is to be
repeated
3
Number-Of-Pairs
Specify in the range from 1
to 99,999.
1
For details about data types, see the table of syntax elements in “ Copy Types and Targets for Which Commands Can
Be Executed” (page 184).
2
Use either of the following methods to specify P-VOL and S-VOL volumes:
• Device number
• Storage system serial number, CU number, and CCA number
If both methods are used, the device number specification takes precedence.
3
For only part of the specified number, the volumes that exist at consecutive addresses are defined as a copy pairs. The
definition depends on the P-VOL and S-VOL specification method:
• When volumes are specified by the device number
Volumes with consecutive device numbers are defined as a copy pair.
• When volumes are specified by the storage system serial, CU, and CCA numbers
Volumes with consecutive CU and CCA numbers are defined as a copy pair.
You must specify 1 even if you do not define copy pairs repeatedly. The following example shows
the copy group definition file that is displayed on the ISPF panel when the following information
is specified:
• PDEVN: 7311
• SDEVN: 2A01
• Number-Of-Pairs: 3
Information displayed on the ISPF panel
CSV Files Used by the Copy Group Definition File Generation Function 351
