Table 151 Device Information Structure (continued)
DescriptionREXX variables
• INIT FAILED
• TIME OUT
• NO RESOURCES AT PRI
• NO RESOURCES AT SEC
• SERIAL# MISMATCH
• CONFIG ERROR
Initiator port numberPri.Port
Target port numberSec.Port
Existence of PSN information (Valid)Info
1
PSN
Physical DKC serial numberPhysicalSerialNum
10
Logical DKC numberLDKCNum
10
1
When the information is acquired, Valid is stored.
2
Information can be acquired for the following models:
• HP StorageWorks XP12000/XP10000 Disk Array
• HP StorageWorks XP24000/XP20000 Disk Array
• HP StorageWorks P9500 Disk Array
3
Information can be acquired for CA.
4
Information can be acquired for TCA.
5
Information can be acquired for CA with consistency group ID specified.
6
Displayed in GMT.
7
Information can be acquired for P-VOL when the status for the CAJ copy pair is PENDING or
DUPLEX.
8
When the emulation type of the journal volume is OPEN-V, NORMAL is displayed.
9
When the copy type is CAJ, and the following models supports the relevant attribute settings,
information is displayed.
• HP StorageWorks XP12000/XP10000 Disk Array
• HP StorageWorks XP24000/XP20000 Disk Array
• HP StorageWorks P9500 Disk Array
When information could not be acquired, the value becomes null.
10
Information can be acquired for HP StorageWorks XP24000/XP20000 Disk Array.
11
This value is invalid for a PPRC copy pair.
12
Only information about a disk connected to the host can be obtained.
Path Set Structure
Table 152 (page 341) shows the path set structure. Prefixes for the name of the path set structure
is stem-name-specified-in-STEM-parameter and PATH.
NOTE: You can use the YKDROP command to drop the REXX variables in any path set structure
that was loaded by using the YKLOAD command.
Each variable is preceded by a period (.).
