HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 146 Copy Group Structure (continued)
DescriptionREXX variables
ModelModelRev
14
• XP10000 or XP12000
• XP20000 or XP24000
• P9500
Serial numberSerialNum
Arbitration command deviceArbCmdNo
15
Arbitration count timeArbCTTime
16, 17
(yyyymmdd hh:mm:ss.nnnnnn)
Journal group registration statusJNLGValid
16
• 0: not registered in EXCTG (when an
error occurs)
• 1: EXCTG registration complete
• 2: EXCTG registration in progress
• 3: EXCTG deletion in progress
Type of journal groupJNLGType
16
• 0: Journal group not in arbitration
• 1: Journal group in arbitration
Journal statusJNLState
16, 18
Error codeErrorCode
16
Number of Stats (number of n)0Stats
Primary storage system serial numberPri_Serialnumn
5
Primary write pending ratePri_WPR_All
Primary reserve sidefile cache-usage ratePri_RSF_All
9
Primary reserve sidefile cache-usage rate
for C/T
Pri_RSF_CT
Secondary storage system serial numberSec_Serialnum
19
Secondary write pending rateSec_WPR_All
Secondary reserve sidefile cache-usage rateSec_RSF_All
9, 19
Secondary reserve sidefile cache-usage rate
for C/T
Sec_RSF_CT
Sidefile thresholdSidefile_Threshold
Offloading timerOffload_Timer
RCU ready timerRCU_Ready_Timer
Copy pending timerCopy_Pending_Timer
Data transmission speed between MCU-RCU
(Kbps)
MCU_TO_RCU_KBPS
19
Metadata % used rate in master journal
volume. The percentage used of the Journal
Pri_JNL_Meta
Metadata capacity available in the Journal
Volume(s) registered to M-JNL.
324 Data Objects
