Dataset Formats and Required Disk Capacity for the Configuration File
This section describes the dataset formats and required disk capacity for the configuration file.
Table 142 (page 302) describes the meaning of the symbols used in the formulas of this section.
Table 142 Meaning of the Symbols Used in the Formulas
MeaningSymbol
Number of copy groups included in the copy group definition fileA
Number of copy pairs included in the copy group definition fileB
Size to be increased when the EXCTG attribute is defined.C
For details about formulas used for calculating the size to be increased, see
Table 145 (page 303).
Size to be increased when the YKSTORE command is used in a script.D
For details about formulas used for calculating the size to be increased, see
Table 145 (page 303).
Number of volumes included in the disk configuration definition fileE
Number of routes included in the route list definition fileF
Number of command devices included in the route list definition fileG
Number of command devices included in the command device definition fileH
Total number of inter-CU logical paths and inter-DKC logical paths that are included in
the path set definition file
I
Number of digits in the number of copy pairs included in the copy group definition fileJ
The configuration file dataset formats are listed in Table 143 (page 302).
Table 143 Configuration File Dataset Format
BLKSIZE(bytes)LRECLRECFMDSORGType of the configuration file
4,096256VBPSCopy group definition file
4,096256VBPSDisk configuration definition file
4,096256VBPSRoute list definition file
4,096256VBPSCommand device definition file
4,096256VBPSPath set definition file
NOTE: The configuration files are only for reference. If the configuration files are changed, correct
operation cannot be guaranteed.
Table 144 (page 302) describes the required disk space for the configuration file. When you estimate
the disk capacity, also consider the need to create backup files, and secure space that is at least
twice the size of the required disk capacity.
Table 144 Required Disk Space for the Configuration File
Size (bytes)Type of the configuration file
600Copy group definition file
+ A x 710
+ B x 230
+ C
