HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

NOTE: When entering a DAD ID, remember the following:
• Specify the same DAD ID for volumes that can be directly accessed. Business Continuity
Manager assumes that volumes with the same DAD ID as the one specified for the Set Defaults
panel can be directly accessed.
• For BC, the same DAD ID must be specified for P-VOL and S-VOL. However, when defining
a Non Gen'ed volume and a Gen'ed volume inside the same storage system as a BC copy
pair, specify the respective values (the DAD ID used during an NG scan and the DAD ID used
during a local scan).
Manage Licenses Panel (License Management)
The Manage Licenses panel is displayed when 2 Manage Licenses is selected in the Main Menu
panel. In the Manage Licenses panel, you can register licenses or display license information.
The Manage Licenses panel is shown in Figure 17 (page 29).
Figure 17 Manage Licenses Panel
Table 11 (page 29) describes the items in the Manage Licenses panel.
Table 11 Contents of the Manage Licenses Panel
DescriptionItem
The dataset name of the license key file that has been transferred to MVS.License Key Dataset Name
Key code of the licenseKey Code
License namePP Name
Physical Storage system serial numberSerial Num
Storage system model codeModel
For details about the displayed values, see Help.
License typeType
• Perm: Permanent license.
• Temp: Temporary license.
• Emer: Emergency license.
Licensed capacity (in TB or Unlimited)Capacity(TB)
Manage Licenses Panel (License Management) 29
