HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

MSG(stem-name-2) ~ <REXX prefix of 64 or fewer characters>
Specify an optional prefix for the name of the message structure used to store the messages to be
generated by this command. You must also include a trailing period character.
The message structure is initialized when the CLI command with the same name as the MSG
parameter is called.
NOTE:
• The YKLOAD command is an REXX subroutine, so it should be called from REXX script by the
REXX CALL key word instruction.
• When you execute the YKLOAD command more than once using the same stem-name, the
system overwrites the REXX variables.
• The invoked script executed from CALL statement or EXEC command should not read a
configuration file with the same stem-name as the one read by the invoking script.
• When operating without a route list, to execute the YKLOAD command several times, specify
the same DAD ID for all the instances of the YKLOAD command. The specified DAD ID should
be the DAD ID assigned to the storage system connected to the host where Business Continuity
Manager is running.
• When operating with a route list, to execute the YKLOAD command several times, specify the
ROUTE parameter for only the first executed instance of the YKLOAD command. For the
succeeding instances of the YKLOAD command, do not specify ROUTE parameter, but specify
the same DAD ID as for the first instance of the YKLOAD command. Note that if you drop the
route list structure, and then execute the YKLOAD command, you need to specify the ROUTE
parameter.
• Do not drop only some of the REXX variable structures created by the YKLOAD command. If
you do this, Business Continuity Manager might not operate properly. If you want to drop
some of the REXX variable structures, make sure that you drop all of them.
• When you issue a command that requires a copy group stem-name as the input condition,
execute the YKLOAD command before executing that command.
• Even if the GROUP parameter is not specified, the YKL007E message is not displayed if the
ROUTE or PATH parameter is specified. If none of the GROUP, ROUTE and PATH parameters
are specified, the YKL201E message will be displayed.
• Do not execute the YKLOAD command by specifying the DAD ID that was specified for the
remote scan or NG scan using the DAD parameter. Doing so will cause an error. This could
occur when, for example, a planned switch is made from the primary site to the secondary
site and the disk configuration definition file of the storage system on the secondary site (as
created by the remote scan) is copied to the secondary host.
Return Codes
Table 122 (page 222) lists the return codes to be returned when the YKLOAD command terminates.
Table 122 YKLOAD Command Return Code List
MeaningReturn Code
The command completed normally.0
Unknown XML attributes or elements encountered in input file.4
Unable to resolve device number for S-VOL in copy pair.8
Unable to resolve volume serial number for P-VOL in copy pair.12
Unable to resolve device number for P-VOL in copy pair.16
222 CLI Commands
