HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

If the specified volume is not found, or an I/O error occurred and the storage system information
cannot be acquired, this command creates an error message in the command return configuration
structure, and then returns a return code other than 0.
This command can be used for volumes of the following models on which FlashCopy Mirror Version
2 is installed:
• HP StorageWorks XP12000/XP10000 Disk Array
• HP StorageWorks XP24000/XP20000 Disk Array
• HP StorageWorks P9500 Disk Array
Parameters
STEM(stem-name-1) ~ <REXX prefix of 64 or fewer characters>
Specify an optional prefix for the name of the FlashCopy information structure used to store the
FlashCopy information. You must also include a trailing period character.
MSG(stem-name-2) ~ <REXX prefix of 64 or fewer characters>
Specify an optional prefix for the name of the message structure used to store the messages to be
generated by this command. You must also include a trailing period character.
The message structure is initialized when the CLI command with the same name as the MSG
parameter is called.
DEVN(device-number) ~ <4-digit hexadecimal number>
Specify a device number for the volume from which the FlashCopy information will be acquired.
This parameter can be specified for locally connected devices only. It cannot be specified for Non
Gen'ed volumes.
Return Codes
Table 115 (page 212) lists the return codes to be returned when the YKFCSTAT command terminates.
Table 115 YKFCSTAT Command Return Code List
MeaningReturn Code
The command terminated abnormally. A possible cause is as follows:
• The user SVC routine has not been included properly.
-4095 to -4040
The module cannot be loaded. Possible causes are as follows:-3
• The library dataset has not been linked.
• The module is protected by the RACF program control function.
An interruption occurred during execution.-1
The command completed normally.0
32
• I/O errors were encountered.
• A change in an I/O configuration definition was detected.
An error occurred while a REXX variable was being written.40
Terminating due to processing errors.44
Terminating due to invalid parameters.48
The command terminated abnormally. The user does not have permission to execute
this command.
128
212 CLI Commands
