HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 113 YKEWAIT Command Return Code List (continued)
MeaningReturn Code
24
• An error occurred when the suspend processing was performed by using the
CAJ ATTIME suspend function.
• The status of the CAJ copy pair was invalid when the suspend processing was
performed by using the CAJ ATTIME suspend function.
• The suspend processing has started because the timeout period had elapsed
when the CAJ ATTIME suspend function was executed.
32
• I/O errors were encountered.
• A change in an I/O configuration definition was detected.
36
• An invalid or unknown element was found in the configuration.
• An inconsistency between a copy group definition and an actual copy group
was detected.
An error occurred while a REXX variable was being written.40
Terminating due to processing errors.44
Terminating due to invalid parameters. This return code appears, for example,
when the copy pair corresponding to the device number specified with the DEVN
parameter is not found.
48
1
If a time-out has taken place, use the YKQUERY command to check the status of the copy pair. If there is a copy pair
where a transition has not taken place, the S-VOL of the copy pair might be ONLINE. Place it OFFLINE and re-execute.
In addition, for CG containers specified by EXCTG ID, check if the journal group has been registered in EXCTG.
YKEXPORT Command
Applies to Business Copy for Mainframe, Continuous Access Synchronous for Mainframe, Continuous
Access Synchronous for Mainframe with the HyperSwap attribute, Continuous Access Asynchronous
for Mainframe, and Continuous Access Journal for Mainframe.
Format
YKEXPORT
1
PREFIX(prefix)
1
GROUP(copy—group–ID)
Function
This is a TSO/E command.
This command reads a specified copy group definition file and creates the following CSV files
based on the copy group information:
• Pair information CSV file
CSV file containing copy pair information in a CG container
• EXCTG information CSV file (created only for a 4x4 configuration)
CSV file containing EXCTG information in a CG container with a 4x4 configuration
Before you execute this command, allocate datasets for the CSV files under the following DD names
and catalog the files:
• Pair information CSV file: OUTPAIR
• EXCTG information CSV file: OUTEXCTG
For details about CSV files, see “CSV Files Used by the Copy Group Definition File Generation
Function” (page 349).
210 CLI Commands
