Table 89 Contents of the Path Set Status of Copy Group Pair Panel
DescriptionItem
Copy group IDCopy Group ID
Specify an action.
• s: Displays the Logical Path Status of Copy Group Pair panel used to
display the status of physical paths in the logical path.
AC
Path typeType
• CU: Inter-control unit logical path
• DKC: Inter-disk controller logical path
Serial number of the primary storage systemSerial#Primary
Primary path IDPathID
When the path type is CU, nothing is displayed.
Primary control unit numberCU
Primary SSIDSSID
Path directionDir
Serial number of the secondary disk controllerSerial#Secondary
Secondary path IDPathID
When the path type is CU, nothing is displayed.
Secondary control unit numberCU
Secondary SSIDSSID
Status of the logical path used by the copy pairStatus
• ESTABLISHED n/n PORT(S): All defined physical paths have been
established (where n indicates the number of defined physical paths).
• ESTABLISHED m/n PORT(S): Among all of the physical paths defined
by the hardware, only those established are displayed (where m indicates
the number of physical paths in the ESTABLISHED status, and n indicates
the number of defined physical paths).
• INVALID: An error has occurred on a physical path.
The path information displayed in the Path Set Status of Copy Group Pair panel differs depending
on the copy type:
• When the copy type is CA/CAA, path information for the inter-control unit logical path in the
copy direction is displayed
• When the copy type is CAJ, path information for the bidirectional inter-disk controller logical
path is displayed.
• When the copy type is BC, no path information is displayed.
The execution result of the YKQRYDEV command with the PATH parameter specified is displayed
in the RC column in the Copy Group Pair Status panel. “ Return codes displayed in the Copy Group
Pair Status panel” (page 169) describes the return codes displayed in the Copy Group Pair Status
panel.
Table 90 Return codes displayed in the Copy Group Pair Status panel
MeaningReturn Code
Successful completion.00
