HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 3 Contents of the Setting Information Panel (continued)
DescriptionItem
The maximum number of messages (message structures) that are
output to the ISPF log when a command is executed
ISPF Log Max
Displays whether the remote DKC control function is applied:Remote DKC Function
• Y: The Remote DKC Control Function is being used.
• N: The Remote DKC Control Function is not being used.
Current route list IDPreset RouteListID
Pressing the F17=DispConf key displays the Setting Information panel:
• Working
• Setting Information
Exception Message Panel
Error messages for various operations are displayed in the Exception Message Panel.
Figure 5 Exception Message Panel
Table 4 (page 16) describes the items in the Exception Message Panel.
Table 4 Contents of the Exception Message Panel
DescriptionItem
Message ID and message text output to the Text in the message structureMessage
Severity output to the Severity in the message structureSev
Additional information output to the Value in the message structureRelated Information
Pressing the Enter key will cause the displayed Exception Message Panel to close. If there are
multiple messages, they can all be viewed by scrolling the panel. Each operation and the messages
output for that operation are stored in the ISPF log. In a single message, a maximum of two lines
are displayed, and the third line and those lines that follow it, if any, not displayed. The third line
and those below it are checked by using the ISPF log.
16 ISPF Panels
