HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

3
If the emulation type of the journal volume is OPEN, JOURNAL is not displayed.
4
The timing for when the defined values are reflected is as shown in Table 56 (page 79), in the item When effective.
5
It is displayed if P-VOL or S-VOL is shared with other copy pairs in the definition (for example, in a 1:n BC copy pair
configuration or when S-VOL for CAA is used as P-VOL for BC).
6
MISMATCH might be displayed. This happens when the device information during definition, as indicated by Primary
Volume and Secondary Volume, differs from the device information reported by the storage system. In this case, the
device information reported by the storage system is displayed in the Pair Volume column. If MISMATCH is displayed,
check the configuration file used, as well as the actual storage system configuration information settings.
NOTE:
• If the copy type in the definitions differs from the actual copy type, the Volume Query
Information panel for the actual copy type is displayed.
• In the following cases, N/A is displayed for the device information:
◦ When the YKQRYDEV command returns an error
◦ When displaying information about a device of a remote storage system if the route list
has not been loaded or the target storage system is not included in the route list
Volume Query Information (CAJ) Panel
If you specify q in AC on the Copy Group Pair Status panel, the YKQRYDEV command is executed
on the P-VOL and S-VOL, and the Volume Query Information (CAJ) panel is displayed for a CAJ
copy pair.
Figure 116 (page 148) shows the Volume Query Information (CAJ) panel.
Figure 116 Volume Query Information (CAJ) Panel
Table 83 (page 148) describes the items in the Volume Query Information (CAJ) panel.
Table 83 Contents of the Volume Query Information (CAJ) Panel
DescriptionItem
Copy group IDCopy Group ID
Copy type at definitionCopy Group Type (in Configuration)
148 ISPF Panels
