HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 82 Contents of the Volume Query Information (CAA) Panel (continued)
DescriptionItem
SN
• For Primary: storage
system serial number for
P-VOL of the copy pair
specified in the Copy
Group Pair Status panel
• For Secondary: storage
system serial number for
S-VOL of the copy pair
specified in the Copy
Group Pair Status panel
DEVN
• For Primary: Device
number for P-VOL of the
copy pair specified in the
Copy Group Pair Status
panel
• For Secondary: Device
number for S-VOL of the
copy pair specified in the
Copy Group Pair Status
panel
The following volume online
information is displayed to
the right of DEVN:
1
• *: Online
• -: Offline
Nothing is displayed when
volume online information
cannot be obtained.
Copy pair status
6, 2
Status
Copy direction in the copy
pair
Dir
Storage system serial
number of the volume which
makes a copy pair
SNPair Volume
SSID for the volume which
makes a copy pair
SSID
CU number of the volume
which makes a copy pair
CU
CCA of the volume which
makes a copy pair
CCA
Device number of the volume
which makes a copy pair
DEVN
1
It is not displayed when the YKQRYDEV command has been executed for the HP StorageWorks XP1024/XP128 Disk
Array.
2
For details about the status of the displayed copy pair, see the table (for CA/CAA) that shows the copy pair statuses of
volumes obtained by using the YKQRYDEV command, in the HP StorageWorks P9000 for Business Continuity Manager
Software User’s Guide. Note that when the device is a command device of either of the following models, CDEV(apid)
is displayed in the Status column (apid: APID):
• HP StorageWorks XP12000/XP10000 Disk Array
• HP StorageWorks XP24000/XP20000 Disk Array
Manage Copy Groups Panel (Copy Group Operation) 147
