Table 81 Contents of the Volume Query Information (CA) Panel (continued)
DescriptionItem
SN
• For Primary: storage system serial number
for the P-VOL of the copy pair specified in
the Copy Group Pair Status panel
• For Secondary: storage system serial
number for the S-VOL of the copy pair
specified in the Copy Group Pair Status
panel
DEVN
• For Primary: Device number for P-VOL of
the copy pair specified in the Copy Group
Pair Status panel
• For Secondary: Device number for S-VOL
of the copy pair specified in the Copy
Group Pair Status panel
The following volume online information is
displayed to the right of DEVN:
1
• *: Online
• -: Offline
Nothing is displayed when volume online
information cannot be obtained.
Copy pair status
7, 2
Status
Copy direction in the copy pairDir
Storage system serial number of the volume
which makes a copy pair
SNPair Volume
SSID for the volume which makes a copy pairSSID
CU number of the volume which makes a copy
pair
CU
CCA of the volume which makes a copy pairCCA
Device number of the volume which makes a
copy pair
DEVN
1
It is not displayed when the YKQRYDEV command has been executed for the HP StorageWorks XP1024/XP128 Disk
Array.
2
For details about the status of the displayed copy pair, see the table (for CA/CAA) that shows the copy pair statuses of
volumes obtained by using the YKQRYDEV command, in the HP StorageWorks P9000 for Business Continuity Manager
Software Users Guide. Note that when the device is a command device of either of the following models, CDEV(apid)
is displayed in the Status column (apid: APID):
• HP StorageWorks XP12000/XP10000 Disk Array
• HP StorageWorks XP24000/XP20000 Disk Array
• HP StorageWorks P9500 Disk Array
3
If the emulation type of the journal volume is OPEN, JOURNAL is not displayed.
4
This value is invalid for CA copy pairs with the HyperSwap attribute.
5
The timing for when the defined values are reflected is as shown in “Contents of the Copy Group Attributes Panel”
(page 79), in the table item of When effective.
6
It is displayed if P-VOL or S-VOL is shared with other copy pairs in the definition (for example, in a 1:n BC copy pair
configuration or when S-VOL for CAA is used as P-VOL for BC).
7
MISMATCH might be displayed. This happens when the device information during definition, as indicated by Primary
Volume and Secondary Volume, differs from the device information reported by the storage system. In this case, the
Manage Copy Groups Panel (Copy Group Operation) 141
