NOTE: N/A displays in the Device Information (DEVN) field in the following cases:
• When the YKQRYDEV command returns an error
• When displaying information about a device of a remote storage system if the route list has
not been loaded or the target storage system is not included in the route list
• When displaying information about a Non Gen'ed volume, and the route list has not been
loaded or the target storage system is not included in the route list.
Volume Query Information (CA) Panel
If you specify q in AC on the Copy Group Pair Status panel, the YKQRYDEV command is executed
on the P-VOL and S-VOL, and the Volume Query Information (CA) panel is displayed for a CA
copy pair.
The Volume Query Information (CA) panel is shown in Figure 113 (page 138).
Figure 113 Volume Query Information (CA) Panel
Volume Query Information (TC)
Command ===> Scroll ===> PAGE
2008/03/11 19:11:45
Copy Group ID . . . . . . . . . : TC
Copy Type(in Configuration): TC Copy Type(from Storage System) : N/A
---------- Primary Volume ---------- --------- Secondary Volume ---------
SN SSID CU CCA DEVN Status Dir SN SSID CU CCA DEVN Status
14002 2340 00 0A 730A* SIMPLEX > 64050 6000 00 00 6000 N/A
C/T ID PROT MODE COPY PACE FENCE LVL Freeze SCP DIF UNIT CONSLOST(P-S)
N/A N/A N/A N/A N/A TRK N-N
Other CopyPair Information
----- Primary/Secondary ----- ---- Pair Volume ----
Type C/T ID SN DEVN Status Dir SN SSID CU CCA DEVN
******************************* Bottom of data ********************************
F1=Help F3=Exit F4=Refresh F7=Backward F8=Forward
Table 81 (page 138) describes the items in the Volume Query Information (TC) panel.
Table 81 Contents of the Volume Query Information (CA) Panel
DescriptionItem
Copy group IDCopy Group ID
Copy group type at definitionCopy Group Type (in Configuration)
Copy types held by the storage systemCopy Group Type (from Storage System)
Storage system serial number of the P-VOL at
definition
SNPrimary Volume
SSID of the P-VOL at definitionSSID
CU number of the P-VOL at definitionCU
CCA of the P-VOL at definitionCCA
Device number of the P-VOL at definitionDEVN
