HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 80 Contents of the Volume Query Information (BC) Panel (continued)
DescriptionItem
SN
• For Primary: storage system serial number
for P-VOL of the Copy pair specified in the
Copy Group Pair Status panel
• For Secondary: storage system serial
number for S-VOL of the copy pair specified
in the Copy Group Pair Status panel
DEVN
• For Primary: Device number for P-VOL of
the copy pair specified in the Copy Group
Pair Status panel
• For Secondary: Device number of S-VOL for
the copy pair specified in the Copy Group
Pair Status panel
The following volume online information is
displayed to the right of DEVN:
1
• *: Online
• -: Offline
Nothing is displayed when volume online
information cannot be obtained.
Copy pair status
6, 2
Status
Copy direction in the copy pairDir
Storage system serial number of the volume
which makes a copy pair
SNPair Volume
SSID of the volume which makes a copy pairSSID
CU number of the volume which makes a copy
pair
CU
CCA of the volume which makes a copy pairCCA
Device number of the volume which makes a
copy pair
DEVN
1
It is not displayed when the YKQRYDEV command has been executed for the HP StorageWorks XP1024/XP128 Disk
Array.
2
See the table (for BC) in the HP StorageWorks P9000 for Business Continuity Manager Software User Guide for details
about obtaining the status of the displayed copy pair using the YKQRYDEV command. Note that when the device is a
command device of either of the following models, CDEV(apid) is displayed in the Status column (apid: APID):
• HP StorageWorks XP12000/XP10000 Disk Array
• HP StorageWorks XP24000/XP20000 Disk Array
• HP StorageWorks P9500 Disk Array
3
If the emulation type of the journal volume is OPEN, JOURNAL is not displayed.
4
The timing for when the defined values are reflected is as shown inTable 56 (page 79) in the table item labeled When
effective.
5
It is displayed if P-VOL or S-VOL is shared with other copy pairs in the definition (for example, in a 1:n BC copy pair
configuration or when S-VOL for CAA is used as P-VOL for BC).
6
MISMATCH might be displayed. This happens when the device information during definition, as indicated by Primary
Volume and Secondary Volume, differs from the device information reported by the SSID. In this case, the device
information reported by the SSID is displayed in the Pair Volume column. If MISMATCH is displayed, check the configuration
file used and the actual storage system configuration information settings.
Manage Copy Groups Panel (Copy Group Operation) 137
