HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Figure 107 CAJ Copy Group Performance Statistics Panel
Table 77 (page 126) describes the items in the CAJ Copy Group Performance Statistics panel.
Table 77 Contents of the CAJ Copy Group Performance Statistics Panel
DescriptionItem
Current timeCurrent Time
Copy group IDCopy Group ID
Primary DAD ID in the copy group definition filePrimary Device Addr. Domain
Secondary DAD ID in the copy group definition fileSecondary Device Addr. Domain
Consistency group ID in the copy group definition fileC/T ID
Subconsistency group ID in the copy group definition filesub C/T ID
Serial number of a storage system of the copy sourcePri-SN
Serial number of a storage system of the copy targetSec-SN
Data transfer rate (KB/s) between a Pri-Array and a Sec-Array
(KB/s).
Kbytes/sData Trans
Operating information between journal groups on Pri-SNPri
• OK: Data transfer between journal groups is proceeding
normally.
• NG: Data transfer is not proceeding normally, possibly
because a path between storage systems is temporarily out
of service.
• STOP: Data transfer has stopped, as for example if all
volumes in a journal group have been suspended.
• N/A: Operating information could not be obtained.
Operating information between journal groups on Sec-SNSec
• OK: Data transfer between journal groups is proceeding
normally.
• NG: Data transfer is not proceeding normally, possibly
because a path between storage systems is temporarily out
of service.
• STOP: Data transfer has stopped, as for example if all
volumes in a journal group have been suspended.
• N/A: Operating information could not be obtained.
126 ISPF Panels
