NOTE:
• Before displaying CAA performance information in this panel, Usage Monitor should have
started from Remote Web Console. If the copy group consists of USPV volumes only, there is
no need to start Usage Monitor.
• For Pri-SN and Sec-SN, information acquired from the storage system is displayed. If the copy
direction is opposite from the direction specified in the copy group definition file, the secondary
and primary storage system serial numbers in the copy group definition file are shown in order
for Pri-SN and Sec-SN.
• The columns where information is not acquired by the storage system and the columns for
copy groups that contain a copy pair whose copy type is not CAA might display N/A because
the values for those columns are not guaranteed.
• When you display the CAJ data transfer rate in this panel, it is necessary that the Usage
Monitor for the control unit (to which the journal volume used by the copy group definition
file belongs) has been started from Remote Web Console, and that the data capture interval
of this Usage Monitor is ten minutes or less.
• If information cannot be acquired from the Sec-Array, the RSF Tot, RSF C/T, and WPR Tot
columns in Sec %s display N/A.
• If information cannot be acquired from the Pri-Array, the SFT, RSF Tot, RSF C/T, WPR Tot and
TRANS Kbytes/s columns in Pri %s, and OFLD min and RCUR min columns in TIMERS display
N/A.
• If an operation is performed on each copy pair or the copy pair directions in the copy group
are mixed, the value for the copy group cannot be guaranteed because the copy pair direction
statuses in the copy group do not match. Match the copy pair statuses and copy pair directions
in the copy group and then re-execute.
You can use the LOCATE and SORT commands in the CAA Copy Group Performance Statistics
panel. For details about how to use each command, see “Command Line Commands” (page 11).
You can specify the following fields for a sort key of the SORT command:
DirectionSorted byName of field
AscendingPri-SN reserved sidefile cache-usage ratePRSFTOT
AscendingPri-SN reserved sidefile cache-usage rate for CTPRSFCT
AscendingPri-SN write pending ratePWPRTOT
AscendingSec-SN reserved sidefile cache-usage rateSRSFTOT
AscendingSec-SN reserved sidefile cache-usage rate for CTSRSFCT
AscendingSec-SN write pending rateSWPRTOT
AscendingData transfer rate between Pri-SN and Sec-SN sites (KB/s)TRANS
AscendingStorage system serial number of the Pri-SNPSN
AscendingStorage system serial number of the Sec-SNSSN
Sort CAA Copy Group Statistics Panel
In the CAA Copy Group Performance Statistics panel, if you press F6=Sort, the Sort CAA Copy
Group Statistics panel for specifying the sorting order is displayed.
Figure 106 (page 125) shows the Sort CAA Copy Group Statistics panel.
