Figure 98 Logical Path Status Panel
Table 72 (page 112) describes the items in the Logical Path Status panel.
Table 72 Contents of the Logical Path Status Panel
DescriptionItem
Path set IDPath Set ID
Type of pathType
• CU: Inter-CU logical path
• DKC: Inter-DKC logical path
Primary storage system serial numberS/NPrimary
Primary path IDPathID
When the path type is CU, nothing is displayed.
Primary CU numberCU
Displays the number of the CU in which a device exists to which the path
operation command is issued.
Primary SSIDSSID
Secondary storage system serial numberS/NSecondary
Secondary path IDPathID
When the path type is CU, nothing is displayed.
Secondary CU numberCU
Displays the number of the CU in which a device exists to which the path
operation command is issued.
Secondary SSIDSSID
Displays the number of physical paths defined for the storage system, if the
number of physical paths detected by the storage system is greater than the
number of paths defined in the path set definition file.
Information
Primary port numberPrimary
Direction of the pathDir
