HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Figure 97 Path Set Status Panel
Table 71 (page 110) describes the items in the Path Set Status panel.
Table 71 Contents of the Path Set Status Panel
DescriptionItem
Path set IDPath Set ID
Specify an action.AC
• s: Displays the Logical Path Status panel used to display status details
for the logical path.
• b: Executes the YKBLDPTH command, and establishes the selected
logical path. The execution result is displayed on the same panel.
• d: Executes the YKDELPTH command, and deletes the selected logical
path. The Confirm Path Delete panel is displayed.
• q: Executes the YKQRYPTH command, and updates the status of the
selected logical path. The execution result is displayed on the same
panel.
When actions are entered in multiple AC columns, each is processed in
the order displayed.
Type of pathType
• CU: Inter-CU logical path
• DKC: Inter-DKC logical path
Primary storage system serial numberSNPrimary
Path ID of the primary siteID
When the path type is CU, nothing is displayed.
Primary CU numberCU
Displays the number of the CU in which a device exists to which the path
operation command is issued.
Primary SSIDSSID
Direction of the pathDir
Secondary storage system serial numberSNSecondary
Path ID of the secondary siteID
When the path type is CU, nothing is displayed.
110 ISPF Panels
