Table 69 Contents of the Command Device Selection List Panel
DescriptionItem
DAD IDDevice Address Domain ID
Description of the storage system specified in the Host-Discovered Array
structure
Description
Storage system modelModel
• 9900V: HP StorageWorks XP1024/XP128
• USP: HP StorageWorks XP12000/XP10000
• USPV: HP StorageWorks XP24000/XP20000 Disk Array
• VSP: HP StorageWorks P9500 Disk Array
Microcode informationuCode
Interface versionIFType
Storage system serial numberS/N
Specify an action.AC
• q: Displays the Command Device Status panel used to display the
command device information, which is registered in the storage system.
• d: Deletes the command device information, which is registered in the
storage system. The Confirm Command Device Delete panel will be
displayed even if Confirm is set to off.
When multiple actions are specified in multiple AC columns, the actions
are executed in order from top to bottom.
Results of the action
1
Status
• Del,nn: Displays the result (RC) of deletion processing for the
command device, in nn format.
• Qry,nn: Displays the result (RC) of display processing for the command
device , in nn format.
SSID of the CU to which the detected command device belongs (2-digit
hexadecimal number)
SSID
Number of the CU to which the detected command device belongs (2-digit
hexadecimal number)
CU
CCA of the detected command device (2-digit hexadecimal number)CCA
Device number of the detected command device (2-digit hexadecimal
number)
Devn
1
If the specified action has been aborted, the execution result (RC) is not displayed correctly.
When the route list definition has been modified or deleted, sometimes the command devices
defined in the old route list remain registered in the storage system. Such command devices can
be accessed directly through this panel.
NOTE: Only devices registered in the disk configuration definition file are displayed. Scan the
target storage system to detect command devices and register them in the disk configuration
definition file in advance.
Manage Path Set Panel (Logical Path Management)
When 5 Manage Path Set is selected in the Main Menu panel, the Manage Path Set panel to
operate path sets is displayed.
Figure 95 (page 108) shows the Manage Path Set panel.
Manage Path Set Panel (Logical Path Management) 107
