HP P9000 Business Continuity Manager Reference Guide (T5253-96058, September 2011)

Table 67 Contents of the Route Status Panel (continued)
DescriptionItem
Specify an action.AC
• q: Displays the Command Device Status panel used to execute the
YKQRYDEV command to display the command device information that
is registered in a storage system.
• b: Executes the YKBLDCMD command to register a command device in
a storage system.
• d: Executes the YKDELCMD command to delete the command device
information that is registered in a storage system.
• f: Displays the Command Device Selection List panel used to detect all
command devices registered with the storage system from the list of
devices registered in the disk configuration definition file.
When multiple actions have been specified in multiple AC columns, they
are carried out in the order b, d, q, and f. When d is selected in multiple
AC columns, the operation proceeds in order from bottom to top. All actions
other than d proceed in order from top to bottom.
Execution result of the action specified for AC.
2
Status
• Qry,nn: Displays the result (RC) of display processing for the command
device, in nn format.
• Bld,nn: Displays the result (RC) of creation processing for the command
device, in nn format.
• Del,nn: Displays the result (RC) of deletion processing for the command
device, in nn format.
• Fnd,nn: Displays the result (RC) of a command device information query,
in nn format.
Route numberRoute Num
Placement (list number) of the entry within the same route numberLst
DAD IDDevice Address Domain ID
Storage system serial numberSerial Number
Device number of the command device.
3
Devn
SSID of the CU to which the command device within the storage system
belongs
SSID
The number of the CU to which the command device within the storage
system belongs
CU
CCA of the command device within the storage systemCCA
Volume serial number for the command deviceVolser
1
If the information cannot be obtained, N/A is displayed.
2
If the specified action has been aborted, the execution result (RC) is not displayed correctly.
3
If a device number has not been assigned, **** is displayed.
A route is a connection between DADs. The Route Status panel displays a route that indicates the
status of the path connection from top to bottom.
NOTE: Status displays the execution result of the action specified for AC. If you specify f for AC
and execute the action, out of the devices registered in the disk configuration definition file, all
command devices that are registered in the storage system are displayed in the Command Device
Selection List panel. If you press the F3=Exit key to exit the Command Device Selection List panel,
Status in the Route Status panel displays the processing result of a command device information
query (Fnd,nn).
