If the specified action has been aborted, the execution result (RC) is not displayed correctly.
When you change or delete the route list, command devices defined in the list can remain registered
in the storage system. You can use this panel to directly operate such devices by entering the
appropriate DAD ID and storage system serial number to specify the storage system, as well as
the device number of the command device. In this case, the command devices that you can operate
are those for which a device number (Devn) is defined in the disk configuration definition file.
Executing YKDELCMD
If you specify d on the Extra Command Device Direct Operation panel, the YKDELCMD command
is executed to delete the command device information registered in the storage system, and the
Confirm Command Device Delete panel (see “Displayed from Extra Command Device Direct
Operation Panel” (page 175)) is displayed.
NOTE:
• When using the HP StorageWorks XP1024/XP128 Disk Array, take the target command
device offline before executing the YKDELCMD command.
• For the following models, you can execute the YKDELCMD command regardless of whether
the target command device is online or offline:
◦ HP StorageWorks XP12000/XP10000 Disk Array
◦ HP StorageWorks XP24000/XP20000 Disk Array
◦ HP StorageWorks P9500 Disk Array
• For the HP StorageWorks XP1024/XP128 Disk Array, you can only delete command devices
registered in storage systems that are directly connected to the host. You cannot delete remote
storage system command devices.
• Take care not to delete command devices defined in the route list.
Route Status Panel (Route Management)
The Route Status panel is displayed when s is specified for the AC column in the Manage Route
panel. The following table shows the Route Status panel when the F11=CCAInfo key is pressed on
the Route Status panel.
F11=CCAInfo keyF10=DADInfo keyItem
DisplayedDisplayedRoute number
List number
Not displayedDAD ID
DisplayedSerial number
Device number
Not displayedSSID
CU number
CCA
Not DisplayedVolume serial number
Figure 89 (page 101) shows the Route Status panel (default display) when the F10=DADInfo key is
pressed.
