Settings for various network configurations
61
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and a mainframe host.
Table 2-9 Port numbers that must be registered as exceptions to a firewall between the
management server and a mainframe host
Port number Originator Destination Remarks
24042/tcp
*
Management server Mainframe host -
Legend:
-: Not applicable
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and an SMI-S provider.
Table 2-10 Port numbers that must be registered as exceptions to a firewall between the
management server and an SMI-S provider
Port number Originator Destination Remarks
5983/tcp
*
SMI-S provider Management server -
5988/tcp
*
Management server SMI-S provider This setting is required when
non-SSL communication is used.
5989/tcp
*
Management server SMI-S provider This setting is required when
SSL communication is used.
Legend
--: Not applicable
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and a CIM client.
Table 2-11 Port numbers that must be registered as exceptions to a firewall between the
management server and a CIM client
Port number Originator Destination Remarks
427/tcp
CIM client Management server -
5988/tcp
*
CIM client Management server This setting is required when
non-SSL communication is used.
5989/tcp
*
CIM client Management server This setting is required when
SSL communication is used.
Legend
--: Not applicable
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and a mail server.
